Description

Warning: Undefined array key "_border_border" in /usr/home/lvlotus/domains/www.spring-wire.org/public_html/wp-content/plugins/elementor/includes/conditions.php on line 87

Shaped wire can save raw material, increase the utilization rate of material and can be delivered with coils or strips, which increasing the productivity of downstream procedures and facilitating the automated industrial production.

Warning: Undefined array key "border_border" in /usr/home/lvlotus/domains/www.spring-wire.org/public_html/wp-content/plugins/elementor/includes/conditions.php on line 87

Warning: Undefined array key "_border_border" in /usr/home/lvlotus/domains/www.spring-wire.org/public_html/wp-content/plugins/elementor/includes/conditions.php on line 87 Warning: Undefined array key "_border_border" in /usr/home/lvlotus/domains/www.spring-wire.org/public_html/wp-content/plugins/elementor/includes/conditions.php on line 87 Warning: Undefined array key "_border_border" in /usr/home/lvlotus/domains/www.spring-wire.org/public_html/wp-content/plugins/elementor/includes/conditions.php on line 87 Warning: Undefined array key "_border_border" in /usr/home/lvlotus/domains/www.spring-wire.org/public_html/wp-content/plugins/elementor/includes/conditions.php on line 87

Warning: Undefined array key "border_border" in /usr/home/lvlotus/domains/www.spring-wire.org/public_html/wp-content/plugins/elementor/includes/conditions.php on line 87

Warning: Undefined array key "_border_border" in /usr/home/lvlotus/domains/www.spring-wire.org/public_html/wp-content/plugins/elementor/includes/conditions.php on line 87

Details

Warning: Undefined array key "_border_border" in /usr/home/lvlotus/domains/www.spring-wire.org/public_html/wp-content/plugins/elementor/includes/conditions.php on line 87

Wire Sort	Steel Grade	Size (mm)	Application
Precision Shaped Steel Wire for Sealing Rings	B55SiCr, SAE9254V, 50CrVA, SUS631, SUS316, SUS302, SUS304, 65Mn, 60Si2Mn, 62A, 72A, 72B, 82B, etc.	Thickness (0.10-8.0) ±0.01 Width (0.3-15.0) ±0.03	Mainly used for special sealing, EH aviation retaining rings, multi-layer sealing retaining rings, precision springs, etc.
Special Shaped Steel Wire for Piston Rings	50CrVA(Bao Steel), 55CrSi(Bao Steel), 55CrSi (imported), 50CrVA(imported), 60Si2Mn (Bao Steel), 65Mn, 70A, 304, etc.	Thickness (0.2-6.0) ±0.005 Width (0.8-10.0) ±0.005	Mainly providing formed strip materials for steel piston rings of various types of gasoline, diesel and natural gas engines。
Trapezoidal Steel Wire	50CrVA, 55CrSi, 55CrSi, 50CrVA, 60Si2Mn, 65Mn, 70A, 304, etc.	TD 3.051.5, TD5.12.45, TD 4.11.6, TD7.12.8	Mechanical Springs, Die Springs, etc.
Rectangular Steel Wire	8Cr17MoV, 6Cr13Mo, SAE9254V, 55CrSi, 60Si2Mn, SWRH72A, SUS304, etc.	1.21.5, 1.52.3, 23, 46, 610, 1012	Suitable for manufacturing mechanical springs and other products that are formed by winding in a cold state and then subjected to low-temperature shaping treatment without the need for quenching.
Flat Wire for Seat Angle Adjuster	60Si2Mn, 65Mn, etc.	17, 1.33, 1.38, 2.58, 29, 2.110, 3.56.5, 37, 38, 3.112,310, 3.416, 3.716, 3.916, 3.2*16	Used for making seat adjusters
Shaped Wire for Spiral Springs	72B, 65MN, 62A, 65MN, 60SI2MN	H series 1.1-4.5 B series 7.0-16.0	Mainly used for automotive springs.
Shaped Steel Wire for Mechanical Springs	50CrVA(Bao Steel), 55CrSi(Bao Steel), 55CrSi (imported), 50CrVA(imported), 60Si2Mn (Bao Steel), 65Mn, 70A, 304, etc.	(1) Square Wire：11, 22, 2.72.7, 33, 44, 66, 88, 1010 (2)Rectangle Wire：1.21.5, 1.52.3, 23, 46, 610, 1012 (3)Trapezoid Wire：TD 3.051.5, TD5.12.45, TD 4.11.6, TD7.12.8 (4)Other Shapes Wire：YX4.888.48, YX3.624.60	Used for manufacturing mechanical springs and other products that are formed by winding in a cold state and then subjected to low-temperature shaping treatment without the need for quenching
Trapezoid Steel Wire for Die Springs	50CrVA(Bao Steel), 55CrSi(Bao Steel), 55CrSi (imported), 50CrVA(imported), 60Si2Mn (Bao Steel)		Used for making Die Springs
High Strength Flat Steel Wire for Hydraulic Press Winding	65Mn, 82A	1.5 5.0, 1.56.0	Mainly used for winding the frame, cylinder body, and crossbeam of large hydraulic presses, and can also be used for winding prestressed containers and pressure structures.

Automotive applications
Industrial Springs
Car Seat Border Springs
Conveyor Belt Fasteners
Gutter Broom
Key Rings
Saw Blade Wire
Frames
Window Mechanisms
Damper Spring Wire
Blender Blade, Mixer Blades
Pocket Tools and Knives
Cotter Pins
Shafts
Gears
Filtration
Eye Glass Frames
Medical Catheter and Guide Wire
Header Bar
Orthodontic Arch Wire
Mesh
Screwdrivers
Agricultural
Snow mobile and ATV
Housing
Electrical

301, 302, 304, 304L, 304H, 316, 316L, 410, 416, 420, 430, 201, etc.
35, 45, 55, 65, 65Mn, 70, 72A, 72B, 82A, 82B, etc.
55CrSi(54SiCr6), SAE9254V, 50CrV, 60Si2Mn, etc.
8Cr17MoV, 6Cr13Mo, etc.

Thickness: 0.1-8.00mm
Width: 0.3-15.00mm

Oil Quenched and Tempered
Cold Drawn & Hard
Annealled & Soft

Square, rounded, Natural rolled, Full Rounded

50-200kg/coil, coils in bundle or on wooden pallet
